Light Duty
PORTABLE LIFTS
333 to 1,500 lb capacity


 LIGHT DUTY PORTABLE LIFTS

The light duty portable lifts are designed to make the lifting, handling and positioning of small parts containers easy on the worker’s back.  For maximum productivity always have your material at an ergonomically convenient work height.


Makes parts easily reachable  –  Prevents back strain  –  Increases productivity.


Capacity options – ELF 330, 660, 770, 1,100, 1,600 lbs, 1,000 & 1,500 lbs



ELF series single scissor PLATFORM SIZES:

24″ wide x 36″ long
24″ wide x 48″ long

BASE SIZES:

17-1/2″ wide x 36″ long
17-1/2″ wide x 48″ long

TRAVEL:

24″ & 36″

SAFETY:

Velocity fuse on all cylinders
Upper limit bypass on ELF units

POWER SUPPLIES:

Foot Pump – manually powered, foot release for controlled lowering
Hand release on ELF units
D/C Battery – Hand held pendant c/w built-in 12 volt 6 amp charger

MAINTENANCE:

Hinged top for easy access to power unit and cylinders
Self lubricated bushings on all pivot points

OPTIONS

• Different platform sizes, consult factory
• Safety skirting
• Rotating platforms




FOR MORE INFORMATION

TO REQUEST A QUOTE CONTACT LIFTWAY AT 1-800-543-8929 OR CLICK THE “Get Quote” BUTTON
