Self Propelled
Portable Lift Tables
2,000 to 6,000 lb capacity


 Self Propelled Lift Tables

Self propelled lift table

2,000 / 3,000 / 4,000 / 5,000 / 6,000 lb capacities


The Self Propelled Lift Table is designed to allow control of lift to precisely position containers or other items at the optimum work height.

  • Makes parts easily reachable
  • Prevents back strain
  • Increases productivity.

self propelled lift table

PLATFORM SIZES
• 24” wide x 36” long to 60” wide
 x 96” long

BASE SIZES
• Standard 24, 36” wide
x 36”, 48”, 60”, 72” long

TRAVEL
• 24”, 36”, 42”, 48”
 vertical travel

LOWERED HEIGHT OF LIFT TABLE
• 12”

SAFETY
• Velocity fuse is standard
on each cylinder
• Heavy duty hydraulic cylinders
  – chrome plated rod with polyurethane seals
• Horn in control head

MAINTENANCE
• Hinged table top
provides easy access to power unit and cylinders
• Self lubricated bronze bushings on all wear points
• Easy removable cover

LIFT TABLE OPTIONS
• Oversized lift table platforms

• Rotating tops
  – spring detents
  – manual detents
• Roller conveyor, Ball transfer tops
• Bellow safety skirting
• Safety tape switch
• Safety touch bars

DRIVE UNIT/ELECTRICS
• 24 volt system

• Variable speed control
  – forward/reverse
• Built in 24 volt charger

Self propelled table options

Standard 24″ Wide Base Self Propelled Tilt Tables

PLT24 Self propelled lift table guide

self propelled lift table guide




36″ Wide Base Self Propelled Tilt Tables

36 wide plt portable lift table chart

FOR MORE INFORMATION

TO REQUEST A QUOTE CONTACT LIFTWAY AT 1-800-543-8929 OR CLICK THE “Get Quote” BUTTON
